Sure, it looks sweet, but this VF Valiant Wayfarer ute also handles the twisty bits better than you’d believe
This article on Andrew’s VF ute was originally published in the March 2010 issue of Street Machine
WE ALL have different motives for building kick-arse street machines. For many it’s the ‘ooh-ahh’ value they get when they take their jalopy for a cruise on Saturday night. For others, it’s the swag of trophies they haul home from the show ’n’ shine or dyno competition. But what we seem to see less of these days — and it’s probably the ingredient most of our cars could do with more of — is driveability.
Does it stop better? Does it go better? Is it fun? Is it reliable? Is it practical and, most of all, is it legal?
You’d have to search far and wide before you came up with a car that answered all those questions better than Andrew Wansey’s Valiant Wayfarer ute.
“I didn’t really plan for things to go this far,” Andrew laughs. “I wanted something that wouldn’t make the enthusiasts cringe if I started to cut it up, like they would over an E49 or a Pacer. I wanted something I could thrash, that would hold its own on the street or at the strip.
“I found this old girl at a caryard on Parramatta Road [Sydney]. It wasn’t flogged like a work ute but it had done some hard miles in the country. It was advertised as a 318 VF ute and I paid about $5000 for it. I remember driving it home only to discover it was a 273 with 318 heads.”
He drove it a good deal further before discovering it had some nasty rust issues in the plenum, just in front of the screen, so he took it to Ray Webb at Pentastar Parts & Repairs, in Sydney’s western suburbs.
“I told Andrew that replacing the dash area and firewall was a big job,” Ray says. “If he was going to go that far, I said he may as well invest more and do the whole car.”
Which he did. “I started thinking about repowering the car,” Andrew says. “I figured it would make the whole project more meaningful so I sourced a good 340 and 727 auto from the US. It had a steel crank, forged rods and big-port X heads — just what we wanted.
“We didn’t need to do much to it apart from add a good cam and Air Gap manifold. Those manifolds were designed to go with those heads so we didn’t need to do any port matching.”
While the car was on the rotisserie in the shop, Andrew decided to fit an AlterKation front-end with drop spindles, tubular control arms, QA1 coil-over shocks, four-spot Wilwood brakes, and rack and pinion steering.
The 318 Andrew bought the car with was really a big-headed 273, so he swapped it for this US import 340, which is filled with quality guts
“I figured I’d build the car so that if the day came when I wanted to drop a big-block in it, the engineer could just tick all the boxes.”
Pentastar Parts & Repairs took over the entire build of the car and fitted a set of mini-tubs to the rear. Rather than go for a heavy nine-inch diff, Ray shortened and braced a BorgWarner unit and fitted it with 3.89:1 gears, Falcon disc brakes and an LSD. The rear springs were also lowered and relocated inside the chassis rails to clear the 17×11 rims and 315 tyres.
Simple but unique changes make the car stand out like a factory one-off. A right-hand drive Dodge Dart dash fascia by Rocky Mountain Dashes is filled with Stewart Warner gauges. It sits well with the ’68 Dodge Charger Grant tiller and the retrimmed VE Valiant low-back bucket seats. All the chrome was blasted and painted in brushed alloy to match the bumblebee stripe across the rear.
Neat original interior? Not quite — the steering wheel’s from a 1968 Dodge Charger, the seats are VE Valiant and the dash is a right-hook Dodge Dart, custom made in the US
“Everything was done by the book: paint stripped, lead wiped and file finished before sitting in polyester and eventually being baked in two-pack,” Ray says.
“You really need to have a good look at the car to notice the subtle changes, like the billet VIP-style grille, built in-house, with textured argent slats and a black face. The hard bed cover is a one-off, just like the fabricated roll pan fitted under the tailgate.”
Finished in Alpine White and rolling on Torque Thrust wheels, the ute has the classic Mopar image with an aggressive road stance.
“We’ve kept the converter small to make the car nice to drive,” Andrew says. “It’s awesome with the upgraded front-end. It really is a case of wherever you point it, it goes. For now, I want to go to a few shows and then we’ll take it to the track.”
FRONTING UP
Look under the front end of any Aussie Valiant, or 60s to 70s US Mopar muscle, and you’ll find torsion bars rather than coil springs holding it up. They’re simple and they work, but they’re also 50-year-old technology. Other than swapping in stiffer torsion bars or better shocks, there hasn’t been too much you can do to improve them — until now.
Reilly Motorsport in the States has created the bolt-in AlterKation kit that not only replaces the torsion bar front end with coil-over suspension, but it also adds rack and pinion steering plus a choice of engine fitments and brake upgrades. The upgrade in suspension technology alone makes the conversion worthwhile but removing the torsion bars and steering box also clears space for a free-flowing exhaust. And the best bit? You can buy the kit right here in Australia from Pentastar Parts and Restorations (02 9608 8888).
“We can supply the kit complete with a crack-test report (AS1554) for engineering in various states,” Ray from Pentastar says. “Every modification on that ute has been signed off by an engineer. It’s definitely an improvement over original. The main thing is, you can tune the front end.”
The AlterKation kit starts at $7500 using the customer’s brakes; you can add options from there. The tubular upper arms are available individually for those who don’t want to go the whole hog.
ANDREW WANSEY
1969 VF VALIANT WAYFARER UTE
Colour: Alpine White
GRUNT
Engine: Chrysler 340
Crank & rods: Forged
Pistons: SRP
Heads: Large-port X
Cam: Comp Cams XE268H
Intake: Air Gap
Carby: 770 Holley
Ignition: MSD
Headers: Pacemaker, dual system
SHIFT
Gearbox: TorqueFlite 727, stage II shift kit, full manual
Converter: B&M 2400
Diff: BorgWarner 3.89:1
BENEATH
Brakes: Wilwood four-spot (f), Falcon discs (r)
Suspension: AlterKation front-end, tubular control arms, rear springs moved inboard, mini-tubs
Shocks: QA1 coil-over shocks (f&r)
Steering: Rack and pinion
INTERIOR
Wheel: Grant 1968 Dodge Charger
Dash: Rocky Mountain Dashes Dart fascia
Gauges: Stewart Warner
Seats: VE Valiant
Stereo: Clarion
Shifter: B&M Quicksilver
ROLLING
Rims: Torque Thrust D, 17×8(f), 17×11(r)
Tyres: 225/65(f), 315/65(r)
